12 V 55 Ah Group 22NF AGM Deep-Cycle DCM0055 Lead-Acid Battery
46444
Orderable12 V 55 Ah Group 22NF AGM Deep-Cycle DCM0055 Lead-Acid Battery
Overview
The 46444 is a 12 V 55 Ah battery commonly used for backup power with the SunSentry™20 Solar Operational Monitoring Met Station. When sourcing batteries locally, the 46444 represents the ideal largest size that will fit into the SunSentry 20 enclosure.
Note: Two 46444 batteries are required to be wired in series when used as a battery backup system for the SunSentry 20, which is a 24 V system. Refer to the SunSentry 20 installation guide for more information.
Specifications
- Battery Type
- Sealed lead acid (SLA)/absorbent glass mat (AGM)
- Output Voltage
- 12 Vdc
- Nominal Rating
- 55 Ah
- Socket Type
- M6 threaded inserts
- Dimensions
- 22.86 x 13.97 x 22.68 cm
(9.0 x 5.5 x 8.93 in.)
- Weight
- 17.24 kg
(38.0 lb)
