Distance up to 15 meters
Overview
The RangeVue™️15 is a non-contact, radar water-level sensor used for monitoring the water level of rivers, lakes, and reservoirs. Using 80 GHz radar technology, it directly measures the distance between the sensor face and the water surface. This distance can be used to determine water level or stage. The sensor is ideal for areas where submersible sensors can be damaged due to corrosion, contamination, flood-related debris, or lightning.
Benefits and Features
- Non-contact water-level measurement
- Meets United States Geological Survey (USGS) Office of Surface Water (OSW) requirements for accuracy
- SDI-12 version 1.4 functionality
- Configurable over SDI-12
- Bluetooth-configurable over smartphone, tablet, or PC
Images
Aspen 10-Compatible IoT Solution
The RangeVue 15 or 30 can be paired with the Aspen™10 Internet of Things (IoT) Edge Device. To get next-gen IoT solutions for advanced water-level monitoring, click the image below:
Specifications
| Measurement Description | Distance |
| Output Options | SDI-12 |
| Measurement Range | 15 m (49.2 ft) |
| Accuracy | ±2 mm (±0.0065 ft) |
| Resolution | 1 mm (0.0033 ft) |
| Radar Frequency | W-band (80 GHz) |
| Beam Angle | 8° |
| Input Voltage | 8 to 30 Vdc |
| Current Drain | 10 mA (at 12 Vdc) |
| Operating Temperature Range | -40° to +80°C |
| Mechanical Rating | IP66/68 IEC 60529, Type 4X/6P UL 50 |
| Material | PVDF, FKM |
| Cable Termination | 4-Pin A-Coded M12 Connector |
| Threads | 1 NPT, 1.5 NPT |
Compatibility
Note: The following shows notable compatibility information. It is not a comprehensive list of all compatible or incompatible products.
Data Loggers
| Product | Compatible | Note |
|---|---|---|
| Aspen 10 | ||
| CR1000 (retired) | ||
| CR1000X | ||
| CR200X (retired) | ||
| CR295X (retired) | ||
| CR300 | ||
| CR3000 (retired) | ||
| CR310 | ||
| CR350 | ||
| CR6 | ||
| CR800 (retired) | ||
| CR850 (retired) |
Communication Devices
| Product | Compatible | Note |
|---|---|---|
| AL200 |
Distributed Data Acquisition
| Product | Compatible | Note |
|---|---|---|
| Granite 6 |
Additional Compatibility Information
The RangeVue 15 interfaces using the SDI-12 communications protocol, and it is compatible with any SDI-12-compliant data recorder, including Campbell Scientific data loggers.
Documents
Videos & Tutorials
Downloads
RangeVue Program Examples (1 KB) 07-12-2024
Two programs use the C1! SDI-12 instruction to measure the RangeVue-series sensors. One program is for the CR350 data logger and one program is for the CR1000X data logger. The program sets the Stage_Reference value to 15.25. This value needs to be changed to your stage reference value. Also, the SDI-12 address is entered as a constant with a value of 0. If the SDI-12 address of the sensor has been changed from the default value, this value needs to be changed to match the sensor address. The program sets the Sensor_Units variable to feet (option 1), which needs to be changed if using other units. See comments in the program for details.
