Tower Mount Kit for ENC24/30
41534

41534

Orderable

Tower Mount Kit for ENC24/30

Pricing

Request a quote Have pricing access? Sign in

Model:
41534
Item Number:
41534

Overview

The 41534 kit enables you to mount one of our painted steel or stainless steel 24 x 30-inch enclosures (ENC24/30, ENC24/30S, ENC24/30UL, or ENC24/30SUL) to a UT6, UT10, UT20, or UT30 tower. The kit's hook feature is installed onto the tower so the enclosure can be more easily hung without requiring someone to hold the enclosure while positioning the fasteners. Clamps are then fastened to the bottom of the enclosure to secure it to the tower.

Note: In the image, the 41534 kit is shown attached to a tower and enclosure. The tower and enclosure are sold separately.

Specifications

Dimensions
60.96 x 10.16 x 10.16 cm

(24 x 4 x 4 in.)

Weight
3.08 kg

(6.8 lb)

Compatibility

Note: The 41534 kit is only compatible with the lower sections of the UT20 and UT30 towers. The kit is not compatible with the upper sections of the UT20 and Ut30 towers.

Compatible Products

(4)
