CM106B

Name: CM106B
Brand: Campbell Scientific
SKU: CM106B
Availability: InStock

7 to 10 ft Galvanized-Steel-Tubing Tripod with Grounding Kit

CM106B

Orderable

7 to 10 ft Galvanized-Steel-Tubing Tripod with Grounding Kit

Pricing

Request a quote Have pricing access? Sign in

Configuration

Flat Black FinishCM106B-BFPart Number: 38345
No Finish**CM106B-NFPart Number: 29631

Qty

Select a configuration to add to your quote

Model:: CM106B
Item Number:: CM106B
Warranty:: 1 year

Overview

The CM106B is an adjustable tripod made of galvanized steel tubing. It is adjustable from 7 to 10 ft. Because the CM106B is made from tubing, it is lighter than our older tripods (CM6 and CM10), which are made with pipe. The CM106B is a general-purpose tripod designed for permanent or temporary installations. It can be used for mounting sensors, solar panels, antennas, and instrument enclosures.

The CM106B can ordered with an optional black powder-coated finish. This finish helps with reflections when using the CM106B to mount solar radiation sensors or other light-sensitive sensors.

Key Advantages

Adjustable, Rugged
Galvanized tubing is strong and corrosion-resistant

Technical Description

The CM106B is constructed with individually adjusted legs that allow installation over uneven terrain. Height of the mast is 2.1 m (7 ft), or 3 m (10 ft) with the mast extended.

The CM106B includes lightning and grounding rods, grounding cables, UV resistant cable ties, and stakes for securing the tripod feet to the ground. An optional guy kit is recommended for sites that may experience high wind speeds. (See Allowable Wind Speeds in the Specifications.) Instrument enclosures can be purchased with mounting brackets that attach to either the mast or leg base.

The CM106B can be used for a variety of applications. For meteorological stations, sensors are mounted to the tripod using mounting brackets appropriate for the model of sensor. For nonmeteorological applications, the tripod can be used to mount instrument enclosures, solar panels, junction boxes, or antennas.

Product Notes

Order the black finish option to avoid reflections off the structure.

Benefits

Support for meteorological sensors, hydrological sensors, sensor mounts, solar panels, environmental enclosures
Portable instrument mount
Lightning and grounding rods, grounding cables, grounding cable clamps, ground stakes, and UV-resistant cable ties included
Enclosures can be mounted on tripod leg, as well as mast
Enclosures mount higher on the leg for easier access
Easy to assemble

Specifications

Vertical Load Limit: 200 kg
(440 lb)
Leveling Adjustment: Slide collars on each leg adjust individually.
Maximum Slope Angle: 45° or 100% grade
Measurement Height: 2.1 to 2.8 m
(7 to 9.3 ft) with upper mast retracted
3 to 3.7 m
(10 to 12.3 ft) with upper mast extended
Leg Base: 11.43 x 13.97 cm
(4.5 x 5.5 in.) with four 1.58 cm (0.62 in.) holes for stakes
Collapsed Diameter: 20.3 cm
(8 in.)
Collapsed Length: 1.83 m
(6 ft)
Main Lower Mast Outer Diameter: 48 mm
(1.90 in.)
Retractable Upper Mast Outer Diameter: 44 mm
(1.74 in.)
Base Diameter: 2.7 to 3.5 m
(8.7 to 11.5 ft)
Weight: 24.5 kg
(54 lb) with mast

Maximum Allowable Sustained Wind

-NOTE-: Allowable sustained wind and wind gust values assume the following:
Sensors (effective area = 1.4 ft²) at top of mastSolar panel (10.5 in. x 16.5 in.) at mast baseEnclosure (14 in. x 16 in.) mounted to legGuy wires attached to mast at 3.8 ft above tripod bodyAdequate ground anchors (stakes alone may not resist foot vertical pullout force)
Mast Extended: 28 m/s
(62 mph) unguyed
45 m/s
(102 mph) guyed
Mast Retracted: 36 m/s
(80 mph) unguyed
55 m/s
(122 mph) guyed

Maximum Allowable Wind Gust

-NOTE-: Allowable sustained wind and wind gust values assume the following:
Sensors (effective area = 1.4 ft²) at top of mastSolar panel (10.5 in. x 16.5 in.) at mast baseEnclosure (14 in. x 16 in.) mounted to legGuy wires attached to mast at 3.8 ft above tripod bodyAdequate ground anchors (stakes alone may not resist foot vertical pullout force)
Mast Extended: 36 m/s
(81 mph) unguyed
59 m/s
(132 mph) guyed
Mast Retracted: 46 m/s
(104 mph) unguyed
71 m/s
(159 mph) guyed

Accessories
(7)

Common Accessories
(3)

Other Accessories
(5)

Replacement Parts
(7)

Ships With
(9)

39572
UV-Resistant 18 in. Cable Ties (quantity of 10)
Orderable
17049
Galvanized Steel Grounding Spike 1/2 x 16
OrderableQty 6
850
Tripod or Tower Lightning Rod
Orderable
17589
Lightning Rod Clamp Assembly
Orderable
2832
Copper-Clad Grounding Rod
Orderable
30338
CM106B Mast Extension Kit
Orderable
2830
Grounding Rod Clamp 1/2-1
Orderable
8 AWG Insulated Copper Stranded Green Wire, 6 ft length
4 AWG Wire, THHN INS Copper Stranded, 4ft length

Enclosure Brackets

Mast

The “-MM” mount option for our environmental enclosures is intended for mounting the enclosure to a tripod's mast. An enclosure ordered with this option will be shipped with a three-piece bracket mounted to the top of the enclosure and an identical three-piece bracket mounted to the bottom of the enclosure.

Leg Base

All of our standard enclosures (including the ENC16/18) can be mounted to the CM106's leg base. The "-LM" mount option for our environmental enclosures allows the enclosure to be attached to the leg base of the CM106. This option includes a metal flange, two brackets, and a 2.5" u-bolt. The brackets attach to the right and left side of the enclosure, and the flange attaches to the tripod near the mast. The flange fits into a notch in one of the brackets, and the other bracket connects to a tripod leg via the u-bolt.
