CM110

Name: CM110
Brand: Campbell Scientific
SKU: 19021
Availability: InStock

10 ft Stainless-Steel Tripod with Grounding Kit

CM110

Orderable

10 ft Stainless-Steel Tripod with Grounding Kit

Pricing

Qty

Model:: CM110
Item Number:: 19021
Warranty:: 1 year

Overview

The CM110 is a 10-foot instrumentation tripod that supports the attachment of sensors, mounts, solar panels, and environmental enclosures. Constructed from stainless steel, the CM110 is easier to transport to remote locations. The tripod can be deployed in uneven terrain and at varying heights. To facilitate sensor attachment, the tripod mast pivots at the leg junction.

Key Advantages

Strong, Tilting Mast
Easy to set up and take down

Technical Description

The CM110 is used as a portable instrument mount in a variety of applications. For meteorological applications, tripods augmented with mounts support the attachment of sensors such as wind sets, pyranometers, and temperature/relative humidity probes. Barometers, soil temperature and moisture probes, and rain gages are also used with tripod-based weather stations. For non-meteorological applications, tripods can provide a portable instrument mount for enclosures and a mounting point for antennas.

UV-resistant cable ties, grounding kit, and six spikes for the tripod feet are included with the CM110.

Two duckbill anchor kits are offered for securing the guy wires (see Ordering Information). Duckbill anchors are not required to use the guy-wire kits. Without them, the guy wires are run from the mast to the feet of the tripod. Duckbill anchors are recommended for areas subjected to higher winds. They allow the guy wires to be anchored at points beyond the feet, thereby increasing the rating of the tripod for higher winds.

The stainless-steel version of the CM110 began shipping in March 2007. Previous versions were made of aluminum.

Benefits

Strong and lightweight
Most joints are locked with pins that are simple to insert and remove
Individually-adjustable legs allow installation over uneven terrain
Includes grounding kit

Specifications

Material: 304 stainless steel
Vertical Load Limit: 45 kg
(100 lb)
Mast Sections: 1
Base Diameter: 2 m
(7 ft) with legs extended
Insert Outer Diameter: 4.45 cm
(1.75 in.)
Height: 3.1 m
(10.5 ft) with mast insert
Dimensions: 15 x 15 x 145 cm
(6 x 6 x 57 in.) of collapsed tripod
Shipping Weight: 15 kg
(34 lb)

Tote Bag

Diameter: 20 cm
(8 in.)
Length: 152 cm
(60 in.)

Wind Load Recommendation

Sustained Wind: 120.7 kph
(75 mph) unguyed
128.7 kph
(80 mph) guyed at feet
Gust Tolerance: 152.9 kph
(95 mph) unguyed
160.9 kph
(100 mph) guyed at feet

Mast

Outer Diameter: 4.8 cm
(1.9 in.)
Pipe Size: 3.81 cm
(1.5 in.) IPS
Length: 1.4 m
(4.6 ft) without insert
2.6 m
(8.6 ft) with insert

Accessories

(8)

Common Accessories

(2)

Other Accessories

(6)

Replacement Parts

(8)

Ships With

(7)

Similar Products

(7)

Compatibility

Enclosures

The ENC16/18 cannot be mounted to the CM110's leg base, as the enclosure is too large for the space.

Enclosure Brackets

The “-MM” mount option for our environmental enclosures is intended for mounting the enclosure to a tripod's mast. An enclosure ordered with this option will be shipped with a three-piece bracket mounted to the top of the enclosure and an identical three-piece bracket mounted to the bottom of the enclosure.

The "-LM" mount option for our environmental enclosures allows the enclosure to be attached to the leg base of the CM110. This option includes a metal flange, two brackets, and a 2.5 in. U-bolt. The brackets attach to the right and left side of the enclosure, and the flange attaches to the tripod near the mast. The flange fits into a notch in one of the brackets, and the other bracket connects to a tripod leg via the U-bolt.
