NL120

Name: NL120
Brand: Campbell Scientific
SKU: 20744
Availability: Discontinued

Ethernet Interface

NL120

End of life

Ethernet Interface

No longer available to order

This product is retained for service, documentation, and compatibility information.

Replaced by

NL121
Ethernet Interface

Model:: NL120
Item Number:: 20744
Warranty:: 1 year

Overview

The NL120 allows the data logger to communicate over a local network or a dedicated Internet connection via TCP/IP. This small, rugged communication device connects directly to the 40-pin peripheral port on a CR1000 or CR3000 datalogger.

Key Advantages

Adds Connectivity
Connects dataloggers to LAN or Internet via Ethernet

Technical Description

The NL120 uses a straight through cable when the cable is run from a hub to the NL120. A 10baseT Ethernet crossover cable is used if the cable is run directly from the computer to the NL120. For cable lengths longer than 9 feet, either a shielded 10baseT Ethernet cable or the 28033 surge protector needs to be used.

The NL120 is set up using the Device Configuration utility (DevConfig). DevConfig is bundled with our PC400, RTDAQ, and LoggerNet software and is available, at no charge, from: www.campbellsci.com/downloads

Product Notes

requires datalogger peripheral port

Benefits

Compatible with CR1000 and CR3000
Connects a data logger to a network
Smallest Ethernet module available for the CR1000 and CR3000

Specifications

Power Requirements: 12 V
(supplied through the data logger’s peripheral port)
Ethernet Speed: 10Base-T (10 Mbps), half-duplex
Typical Current Drain: 20 mA
Dimensions: 10.2 x 6.4 x 2.8 cm
(4.0 x 2.5 x 1.1 in.)
Weight: 66.62 g
(2.35 oz)

EMI and ESD Protection

European Standards: Meets requirements for a class A device under European Standards.
Application of Council Directive(s): 89/336/EEC as amended by 89/336/EEC and 93/68/EEC
Standards to Which Conformity Is Declared: EN55022-1; 1995 and EN50082-1: 1992

Software Requirements

LoggerNet: Version 3.2 or later
PC400: Version 1.3 or later
DevConfig: Version 1.5 or later

Accessories

(7)

Common Accessories

(5)

Other Accessories

(2)

Compatibility

Ethernet Cable

A 10baseT Ethernet straight through cable is used when the cable is run from a hub to the NL120. A 10baseT Ethernet crossover cable is used if the cable is run directly from the computer to the NL120. For cable length longer than 9 ft, the 10baseT Ethernet cable must be shielded or the 28033 surge suppressor must be used.

Data Logger Considerations

The NL120 fastens onto the data logger's 40-pin peripheral port. This means that the NL120 is only compatible with the CR1000 and CR3000. It is NOT compatible with the CR800, CR850, CR200X, CR5000, or CR9000X dataloggers.
