WINDSONIC1

2-D Sonic Wind Sensor with RS-232 Output
WINDSONIC1

WINDSONIC1

Orderable

2-D Sonic Wind Sensor with RS-232 Output

Pricing

Sign in for pricing
Model:
WINDSONIC1
Item Number:
44379
Warranty:
1 year

Overview

The WindSonic1 is a two-dimensional ultrasonic anemometer for measuring wind direction and speed. It provides an alternative to traditional mechanical cup and vane or propeller and vane anemometers. This sonic wind sensor outputs an RS-232 signal that can be directly read by a current Campbell Scientific data logger.

The WindSonic1 is not recommended for conditions where rime, ice, or horizontal snow will occur. This sensor is not heated. Please contact Campbell Scientific for information on a heated 2-D sonic anemometer that will work in these conditions.

Note: The mounting equipment supplied with this sensor may vary depending on which Campbell Scientific regional office the sensor is ordered from.

Key Advantages

No Moving Parts
Minimizes routine maintenance costs

Technical Description

The WindSonic1 uses two pairs of orthogonally oriented transducers to sense the horizontal wind. The transducers bounce the ultrasonic signal from a hood, thus minimizing the effects of transducer shadowing and flow distortion.

Unlike mechanical anemometers, the WindSonic1 has no moving parts to be periodically replaced—minimizing routine maintenance costs.

Four WindSonic1 anemometers can be connected to a single CR1000, CR3000, CR300, CR310, CR6, or CR1000X datalogger. Two WindSonic1 anemometers can be connected to a single CR800 or CR850 datalogger.

Benefits

  • Low maintenance—no moving parts significantly reduces maintenance cost and time
  • Provides a minimum detectable wind speed of 0.01 meters per second
  • Compatible with the SDM-SIO1A, which increases the number of sensors one data logger can measure

Specifications

Applications
General

(Rain with light snow. Little or no riming or blowing sand. No salt spray.)

Extreme

(Blowing sand. Very little maintenance required. Will handle salt spray.)

Sensor
2-dimensional ultrasonic anemometer
Measurement Description
Wind speed and direction
Input Voltage
9 to 30 Vdc
Typical Current Drain
~15 mA

(continuous)

Operating Humidity Range
< 5% to 100% RH
Operating Temperature Range
-35° to +70°C
Storage Temperature Range
-40° to +80°C
Measurement Frequency
40 Hz block averaged to a 1 Hz output frequency
Outputs Parameters
Polar (direction and speed) or orthogonal (Ux and Uy wind)
Output Signal
RS-232
Maximum Cable Capacitance
2500 pF
Maximum Cable Length
15.24 m

(50 ft)
For configurations requiring longer cable lengths, consider using the WindSonic4-L 2-D Sonic Wind Sensor with SDI-12 Output instead, or contact Campbell Scientific for other options.

Diameter
14.2 cm

(5.6 in.)

Length
16.0 cm

(16.3 in.)

Weight
0.5 kg

(1.1 lb)

Wind Direction

Range
0º to 359°

(no dead band)

Accuracy
±3°
Resolution
1°

Wind Speed

Range
0 to 60 m/s
Accuracy
±2%

(@ 12 m s-1)

Resolution
0.01 m/s

Ships With

(4)

Similar Products

(10)

Compatibility

Mounting

The WindSonic1 is shipped with the 17387 mounting kit. This mounting kit is used to attach the sensor to a CM202, CM204, or CM206 crossarm. The crossarm is then mounted to a tripod or tower.

Compatible Products

(1)
