RAVEN110

Name: RAVEN110
Brand: Campbell Scientific
SKU: RAVEN110
Availability: Discontinued

GPRS/EDGE Cellular Digital Modem

RAVEN110

End of life

GPRS/EDGE Cellular Digital Modem

No longer available to order

This product is retained for service, documentation, and compatibility information.

Replaced by

RV50
Industrial 4G LTE Cellular Gateway

Model:: RAVEN110
Item Number:: RAVEN110

Overview

The Raven110 was an Airlink product intended for AT&T digital cellular networks. This full-duplex modem transmitted data to the local cellular tower using either a GPRS or EDGE network. The data was sent from the tower to the base station computer via the Internet. Communicating via Internet provided faster communication rates and eliminates dialing delays and long distance fees.

Specifications

Description: Quadband EDGE (MS class 10) with dualband GPRS (MS-12) fallback
EDGE Quadband: 1900/850 MHz and 1800/900 MHz
GPRS Dualband: 1900/850 MHz
Transmit Frequency: 1850 to 1910 MHz and 824 to 849 MHz
Transmit Power: 1.0 W for 1900 MHz
2.0 W for 850 MHz
Receiver Frequency: 1930 to 1990 MHz and 869 to 894 MHz
EDGE Throughput: Up to 384 kbps
GPRS Throughput: Up to 70 kbp
RS-232 Data Rates: 1200 bps to 115.2 kbps
Operating Temperature Range: -30° to +70°C
(10% duty cycle limit above 60°C)
Serial Interface: RS-232
