BP12
BP12
Orderable12 Ah 12 V Sealed Rechargeable Battery with Mounts
Overview
The BP12 is a rechargeable, 12 V, 12 Ah battery pack that can power a Campbell Scientific system that has components that have above-average power requirements, such as satellite transmitters.
Technical Description
The BP12 requires a regulated charging source (provided by the CH150 or CH200 regulator connected to an unregulated solar panel or a wall charger). The BP12 includes a 24 in. attached cable that terminates in a connector for attaching the battery to a CH150 or CH200 regulator. The BP12 also comes with a 24 in. cable for use with the CR6 datalogger or other products that need a pigtail termination instead of a white connector. (This cable is bagged and taped to the battery.) Switching the standard cable for the pigtail cable is easily accomplished by the user. The BP12 is shipped with hardware for mounting the battery in our enclosures. An ENC16/18 or larger enclosure is recommended.
Specifications
- Battery Type
- Sealed lead acid (SLA)
- UL Approval File Number
- MH16464
- Output Voltage
- 12 Vdc
- Nominal Rating
- 12 Ah
- Battery Cables Length
- 0.6 m
(2 ft)
- Dimensions for Battery Alone
- 15.1 x 9.8 x 9.7 cm
(5.94 x 3.86 x 3.82 in.) for length x width x height
- Dimensions for Battery with Mounting Bracket
- 16.8 x 10.4 x 10.0 cm
(6.61 x 4.10 x 3.94 in.) for length x width x height
- Weight
- 4.4 kg
(9.8 lb)
Accessories
(1)
Other Accessories
(2)27758
BP12 Secured Mounting Kit
The 27758 is a mounting bracket kit that can be used instead of the 8061. It is for customers who require more secured mounting.
OrderableCH201
12 V Charging Regulator
The CH201 is a microcontroller-based smart charge controller that is ideal for charging 12 Vdc VRLA batteries. The charger uses MPPT (maximum power point tracking) technology to safely manage amperage and voltage for optimal battery charging and longevity. It has dual inputs for use with a solar panel and/or any 15 to 50 Vdc charging source. The dual inputs provide the option for fail-safe charging. The CH201 also outputs various parameters to allow close monitoring of the battery and power usage.
Orderable
Replacement Parts
(8)8062
12 Ah 12 V Sealed Rechargeable Battery without Mounting Hardware for BP12
The 8062 provides the BP12's sealed rechargeable battery but without mounting hardware for attaching the battery to an enclosure backplate. This product should be selected when a replacement battery is required, an enclosure will not be used, or you intend to use a custom mount.
Orderable33446
BP12 Mounting Kit
The 33446 kit provides the necessary mounting hardware for users who would like to supply their own 12 Ah 12 V sealed rechargeable battery instead of using the BP12 battery. The 33446 kit can also be used with the 8062 (BP12 battery without mounting hardware).
Orderable30401
BP12 and BP24 Battery Cable with Pigtail
This 24 in. battery cable came bagged and taped to the BP12 battery. One end terminates in clips to connect to the battery's post. The other end terminates in stripped pigtails to be connected to a CR6 datalogger, a CR200X-series datalogger, or other products needing a pigtail connection to a battery. The 30401 may be purchased to replace a lost or damaged cable, or it may be purchased by those supplying their own batteries locally.
Orderable34031
BP12 and BP24 10 A Battery Cable
This 24 in. battery cable comes attached to the BP12 and BP24 batteries. One end terminates in clips to connect to the battery's post. The other end terminates in a white connector to plug into a CH150, CH200, CH100, PS150, PS200, or PS100.
Orderable8061
BP12 Shelf Mounting Bracket
The 8061 is the main component of the BP12's mounting hardware (without grommets, screws, and Velcro strap). Four #505 screws and four #6044 grommets attach the bracket to an enclosure backplate. The 5207 Velcro strap secures the battery to the 8061 bracket.
Orderable5207
Velcro Strap, 1 in. x 18 in.
The 5207 holds the battery to the 8061 bracket.
Orderable505
Screw #6-32 x .375 Pan Phillips
Four 505 screws are used to attach the 8061 bracket to an enclosure backplate. Four 6044 grommets are also required.
Orderable6044
Grommet for #6 or #8 Screw
Four 6044 grommets are used to attach the 8061 bracket to an enclosure backplate. Four 505 screws are also required.
Orderable
Similar Products
(7)BP24
24 Ah 12 V Sealed Rechargeable Battery
OrderableBP84
84 Ah 12 V Sealed Rechargeable Battery
Orderable6182
Replacement 7 Ah Sealed Rechargeable Battery for PS100 or PS150
OrderableBP7
7 Ah 12 V Sealed Rechargeable Battery
Orderable8062
12 Ah 12 V Sealed Rechargeable Battery without Mounting Hardware for BP12
Orderable10075
BP24 24 Ah 12 V Sealed Rechargeable Battery without Mounting Hardware
Orderable10590
ET Sealed Rechargeable Battery without Mounting Hardware
Orderable
Compatibility
Compatible Products
(7)ENC10/12
Weather-Resistant Enclosure, 10 x 12 inches
OrderableNotes—ENC10/12R
Raised Lid Enclosure, 10 x 12 inches
OrderableNotes—ENC12/14
Weather-Resistant Enclosure, 12 x 14 inches
OrderableNotes—ENC14/16
Weather-Resistant Enclosure, 14 x 16 inches
OrderableNotes—ENC16/18
Weather-Resistant Enclosure, 16 x 18 inches
OrderableNotes—34031
BP12 and BP24 10 A Battery Cable
OrderableNotes—34029
7 Ahr 10A Power Cable for PS100, PS150, or PS200
OrderableNotes—
