CR6

Name: CR6
Brand: Campbell Scientific
SKU: CR6
Availability: InStock

High-Capacity Data Acquisition System

CR6

Orderable

High-Capacity Data Acquisition System

Pricing

Configuration

No Additional Coms -40 to +70C Campbell Calibration**CR6-NA-ST-CCPart Number: 28384
No Additional Coms -40 to +70C ISO17025 Calibration**CR6-NA-ST-ICPart Number: 44335
No Additional Coms -55 to +85C Campbell Calibration**CR6-NA-XT-CCPart Number: 42006
No Additional Coms -55 to +85C ISO17025 Calibration**CR6-NA-XT-ICPart Number: 42005
w/900MHz Radio -40 to +70C Campbell Calibration**CR6-RF407-ST-CCPart Number: 32299
w/900MHz Radio for use in Australia/NZ -40 to +70C Campbell CalibrationCR6-RF412-ST-CCPart Number: 32300
w/868MHz Radio for use in EMEA -40 to +70C Campbell CalibrationCR6-RF422-ST-CCPart Number: 32301
w/Radio for use in Brazil -40 to +70C Campbell CalibrationCR6-RF427-ST-CCPart Number: 33779
w/1W 900MHz Radio -40 to +70C Campbell Calibration**CR6-RF452-ST-CCPart Number: 40388
w/Wireless Modem -40 to +70C Campbell Calibration**CR6-WIFI-ST-CCPart Number: 30742

Qty

Select a configuration to add to your quote

Model:: CR6
Item Number:: CR6
Warranty:: 3 years

Overview

The CR6 High-Capacity Data Acquisition System (High-Cap DAQ), designed on decades of infrastructure and environmental monitoring experience, is used by some of the largest monitoring networks worldwide. With the unique ability to serve both as an edge device and gateway, this simplifies networks that would otherwise require discrete devices to provide complete access to your data.

This unique system is used where reliability, flexibility, and compatibility are essential to your success. The CR6 ecosystem supports an array of powerful peripherals that add channel capacity, distributed measurements, and communications capabilities, as well as measure vibrating wire sensors dynamically.

Campbell Scientific’s vibrating wire measurement devices, including the CR6, are the only devices that use patented VSPECT™ technology. VSPECT filters external noise from your sensor and gives you diagnostic information about the quality of your vibrating wire measurement.

Learn about our patented VSPECT at our VSPECT Essentials web resource.

The dynamic vibrating wire measurement technique is protected under U.S. Patent No. 8,671,758, and the vibrating wire spectral-analysis technology (VSPECT) is protected under U.S. Patent No. 7,779,690.

Key Advantages

Rugged, Wireless Edge Device and Gateway with Universal Channels and VSPECT™ Technology
Designed for critical, expanding applications in geotechnical, structural health, and environmental data monitoring projects

Technical Description

The CR6 is the only High-Capacity Data Acquisition System currently available that operates as an edge device and gateway with connectivity, provides an industry standard for rugged design, has universal sensor compatibility and communications options, and includes VSPECT for vibrating wire measurements.

Edge and Gateway Device

The variability and site-specific challenges and constraints that exist in robust monitoring networks typically result in a wide array of devices to achieve full functionality. With built-in and modular measurement, processing, control, and communications capabilities, the CR6 is the only device that is needed.

As a gateway device, the CR6 converts the data measured into the format or protocol required to seamlessly communicate on your network—whether on your computer or the cloud. Entry into the network does not require a separate edge device, as the CR6 also fills this role. Additionally, the CR6 forms a network as a connectivity device via spread-spectrum radio, Wi-Fi, serial, and RS-485.

Using the CR6 as an edge device and gateway with connectivity allows you to standardize on a single platform in your monitoring program. This simplifies purchasing, inventory management, and an overall required knowledge base. The CR6 is capable of a wide range of more than thirty-five M2M protocols that include PakBus, MQTT, DNP3, IPv4, IPv6, HTTP/HTTPS, and PPP. Connectivity options include cellular, radio, satellite, Ethernet, and Wi-Fi. These communications methods enable access to critical data and the ability to receive alarms triggered by user-configured thresholds and events.

Native Vibrating Wire Using VSPECT

VSPECT, Campbell Scientific’s patented technology for measuring vibrating wire sensors, significantly improves vibrating wire sensor measurements—regardless of the manufacturer of the sensor. For more details about this unique technology, visit our VSPECT Essentials web resource.

Integrated Benefits for Simplicity and Reduced Costs

The integrated benefits and capabilities of the CR6 make it the most flexible data acquisition system available. In addition to several spread-spectrum radio options that are compatible with available frequencies across the world, it also includes Wi-Fi, Ethernet, and compatibility with modular cellular and satellite modems. Using Campbell Scientific communications peripherals ensures complete compatibility and extremely low power consumption.

The built-in charge regulator, with direct connections for main power or solar panels, is used to keep your battery charged. An intelligently designed and maintained power supply ensures long-term functionality and helps to capture data from critical events when you need it.

With regular data collection intervals or remote access, the 4 MB of onboard CR6 memory will likely be sufficient. However, if your application requires high measurement frequency; long, unattended deployments; or data storage redundancy, the CR6 has built-in expandable memory via a microSD card.

Communications Options

The CR6 High-Capacity Data Acquisition System is available in different integrated communications frequency radio options.

CR6-WIFI

The CR6-WIFI comes factory-configured as a Wi-Fi access point. Alternatively, the CR6-WIFI can be configured to join an existing Wi-Fi network with standard or Enterprise (EAP) security.

CR6-RF407

This 900 MHz, 250 mW, frequency-hopping spread-spectrum radio option can join a high-speed “mesh topology” radio network of other CR6s, which is ideal for medium-range, license-free radio communications.

CR6-RF412

Designed primarily for unlicensed operation in Australia and New Zealand, this 922 GHz, 250 mW, frequency-hopping spread-spectrum radio can join a high-speed “mesh topology” radio network of other CR6s and is also ideal for medium-range, license-free radio communications.

CR6-RF422

Used in the UK and EU and ideal for short- to medium-range, license-free radio communications, this 868 MHz, 25 mW option includes listen-before-talk (LBT) and adaptive-frequency-agility (AFA). It can join a high-speed “mesh topology” radio network of other CR6s using the included RF422 radio.

CR6-RF452

With this internal 900 MHz, 1 W, frequency-hopping spread-spectrum radio option, the CR6-RF452 can be part of a “star topology” network where all radio-frequency (RF) traffic routes back through the gateway. This option is ideal for long-range, license-free radio communications.

Universal Measurement and Control Terminals

The Universal or “U” terminals allow each terminal to be configured to measure a multitude of different types of sensor outputs. This allows the CR6 to be used in many different applications, regardless of the sensor types required—analog, digital, smart, or vibrating wire. This nearly limitless array of sensors includes inclinometers, meteorologic, hydrologic, piezometers, water quality, etc. The flexibility of Universal channels allows you to standardize on a single monitoring platform for all projects.

Support Staff

Recognized for more than 50 years for our outstanding customer support, Campbell Scientific includes experienced product engineering teams, knowledgeable technical support, attentive sales staff, and market-focused professionals who are committed to ensuring your success throughout the lifetime of your project.

Rugged Design

Unique to all CR6 High-Capacity Data Acquisition Systems is the design and manufacturing process used to ensure operational integrity in the most extreme environments. Each CR6:

Includes surge electrostatic discharge (ESD) and overvoltage protection, as well as dust protection.
Is fully tested for shock and vibration tolerance.
Is factory chamber tested for its full operational temperature range (standard range -40° to +70°C and extended range -55° to +85°C).
Has been proven in hundreds of real-world applications.

These extreme measures are required to manufacture a product with a meantime between failure (MTBF) of 557 years! This means that if you purchase a CR6 today, your probability of failures during the warranty period (three years) is 0.6%. The CR6 High-Capacity Data Acquisition System will last the entirety of your project, even if that means decades.

Benefits

All-in-one edge device and gateway with built-in connectivity
Native vibrating wire measurements using VSPECT
Integrated communications options, charge regulator, and expandable storage to provide simplicity and reduced costs
Configurable Universal (U) measurement and control terminals to measure virtually any sensor or application
Availability of Campbell Scientific qualified support staff
Designed and manufactured for long-term operation in extreme environments

Specifications

-NOTE-: Additional specifications are listed in the CR6 Specifications Sheet.
This information applies to CR6 dataloggers with serial numbers 7502 and newer. These data loggers have two blue stripes on the label.
Operating Temperature Range: -40° to +70°C
(standard)
-55° to +85°C
(extended)
Non-condensing environment
Maximum Scan Rate: 1000 Hz
Case Material: High-impact-resistant polycarbonate and UV-resistant TPE, recycle code 7
Analog Inputs: Up to 12 single-ended or 6 differential
(The CR6 has 12 universal [U] and 4 control [C] terminals that can be programmed for a variety of functions. The number of analog inputs, switched excitations, and digital ports assume all the ports are configured the same.)
Universal Inputs: 12 individually configured inputs for analog or digital functions
Pulse Counters: 16
(C1 to C4 and U1 to U12)
Communications Ports: Ethernet
USB Micro B
CS I/O
CPI
RS-485
RS-422
SDI-12
Data Storage Ports: microSD
Switched 12 Volt: 2 terminals
Digital I/O: 16 terminals (C1 to C4, U1 to U12) configurable for digital input and output.
Terminals are configurable in pairs for 5 V or 3.3 V logic for some functions.
Input Limits: ±5 V
Analog Voltage Accuracy: Accuracy specifications do not include sensor or measurement noise.
±(0.04% of measurement + offset) at 0° to 40°C
±(0.06% of measurement + offset) at -40° to +70°C
±(0.08% of measurement + offset) at -55° to +85°C
(extended temperature range)
ADC: 24-bit
Charge Terminal Characteristics (CHG+ and CHG-): Input from power converter or solar panel
ES1 PS2 energy sources only
(Energy Source Class 1 [ES1] and Power Source Class 2 [PS2], as defined in Clauses 5 and 7 of IEC/AS/NZS 62368-1:2022)
16 to 32 Vdc
Input current limit @ 12 Vdc
Hold current limit 1.1 A @ 20°C
Battery Terminal Characteristics (BAT+ and BAT-): Voltage input 12 Vdc only
Hold current limit 2.5 A @ 20°C
Real-Time Clock Accuracy: ±3 min. per year
(optional GPS correction to ±10 µs)
Internet Protocols: Ethernet, PPP, RNDIS, ICMP/Ping, Auto-IP (APIPA), IPv4, IPv6, UDP, TCP, TLS (v1.2), DNS, DHCP, SLAAC, Telnet, HTTP(S), SFTP, FTP(S), POP3/TLS, NTP, SMTP/TLS, SNMPv3, CS I/O IP, MQTT
Communications Protocols: CPI, PakBus, SDM, SDI-12, Modbus, TCP, DNP3, UDP, NTCIP, NMEA 0183, I2C, SPI, and others
Battery-backed SRAM for CPU Usage & Final Storage: 4 MB
Data Storage: 4 MB SRAM + 72 MB flash
(Storage expansion of up to 16 GB with removable microSD flash memory card.)
Idle Current Drain, Average: Assumes 12 Vdc on BAT terminals; add 2 mA if using CHG terminals.
< 1 mA
Active Current Drain, Average: Assumes 12 Vdc on BAT terminals; add 2 mA if using CHG terminals.
3 mA
(1 Hz scan)
67 mA
(20 Hz scan)
Static Vibrating Wire Measurements: Supported
Dimensions: 21.0 x 10.2 x 5.6 cm
(8.3 x 4.0 x 2.2 in.)
Additional clearance required for cables and leads.
Weight: 0.42 to 0.52 kg
(0.92 to 1.15 lb) depending on communication option selected

CR6-RF407 Option

Radio Type: Frequency Hopping Spread Spectrum
(FHSS)
Output Power: 5 to 250 mW
(user-selectable)
Frequency: 902 to 928 MHz
(US, Canada)
RF Data Rate: 200 kbps
Receive Sensitivity: -101 dBm
Antenna Connector: RPSMA
(External antenna required; see www.campbellsci.com/order/rf407 for Campbell Scientific antennas.)
Idle Current Drain, Average: 12 mA
(@ 12 Vdc)
Active Current Drain, Average: < 80 mA
(@ 12 Vdc)

CR6-RF412 Option

Radio Type: Frequency Hopping Spread Spectrum
(FHSS)
Output Power: 5 to 250 mW
(user-selectable)
Frequency: 915 to 928 MHz
(Australia, New Zealand)
RF Data Rate: 200 kbps
Receive Sensitivity: -101 dBm
Antenna Connector: RPSMA
(External antenna required; see www.campbellsci.com/order/rf412 for Campbell Scientific antennas.)
Idle Current Drain, Average: 12 mA
(@ 12 Vdc)
Active Current Drain, Average: < 80 mA
(@ 12 Vdc)

CR6-RF422 Option

Radio Type: 868 MHz SRD 860 with listen-before-talk (LBT) and adaptive-frequency-agility (AFA)
Output Power: 2 to 25 mW
(user-selectable)
Frequency: 863 to 870 MHz
(UK and EU)
RF Data Rate: 10 kbps
Receive Sensitivity: -106 dBm
Antenna Connector: RPSMA
(External antenna required; see www.campbellsci.com/order/rf422 for Campbell Scientific antennas.)
Idle Current Drain, Average: 9.5 mA
Active Current Drain, Average: 20 mA

CR6-RF427 Option

Radio Type: Frequency Hopping Spread Spectrum
(FHSS)
Output Power: 5 to 250 mW
(user-selectable)
Frequency: 902 to 907.5 MHz/915 to 928 MHz
(Brazil)
RF Data Rate: 200 kbps
Receive Sensitivity: –101 dBm
Antenna Connector: RPSMA
(External antenna required.)
Idle Current Drain, Average: 12 mA
(@ 12 Vdc)
Active Current Drain, Average: < 80 mA
(@ 12 Vdc)

CR6-RF452 Option

Radio Type: Frequency Hopping Spread Spectrum
(FHSS)
Output Power: 10 to 1,000 mW
(user-selectable)
Frequency: 902 to 928 MHz
RF Data Rate: 115.2 or 153.6 kbps
(selectable speeds)
Receiver Sensitivity: -108 dBm at 115.2 kbps
(for 10^-4 BER)
-103 dBm at 153.6 kbps
(for 10^-4 BER)
RF Connector: Reverse Polarity SMA (RPSMA) jack
(external antenna required)
Idle Current Drain, Average: 15 mA
(@ 12 Vdc)
Active Current Drain, Average: 650 mA
(@ 12 Vdc)

CR6-WIFI Option

Operational Modes: Client or Access Point
Operating Frequency: 2.4 GHz, 20 MHz bandwidth
Antenna Connector: RPSMA
Antenna: pn 16005 unity gain (0 dBd), 1/2 wave whip, omnidirectional with articulating knuckle joint for vertical or horizontal orientation
Transmit Power: 7 to 18 dBm
(5 to 63 mW)

Accessories

(22)

Common Accessories

(29)

Other Accessories

(2)

Replacement Parts

(19)

Services

(3)

Need Something Not Listed?

(CR6)

Don't see what you need from among these options? Download the complete configuration list below.

View all product configurations

Ships With

(6)

Similar Products

(9)

Compatibility

Sensors

With several terminal types, the CR6 is compatible with nearly every available sensor, including analog (both voltage and current), thermocouples, serial, SDI-12, vibrating wire, pulse, and frequency sensors.

Measurement and Control Peripherals

The CR6 is compatible with all CDMs, multiplexers, vibrating wire interfaces, terminal input modules, and relays.

Communications

The CR6 communicates with a PC via direct USB port, 10/100baseT Ethernet port, Wi-Fi, multidrop modems, short-haul modems, phone modems (land-line, digital cellular, and voice-synthesized), RF telemetry, and satellite transmitters (HDR GOES, Argos, Meteosat, Iridium, and Inmarsat).

Data can be viewed on an iOS or Android device.

Data Logger Option	Radio Type	Integrated Radio Is Over-the-Air Compatible With
CR6-WIFI	2.4 GHz, 20 MHz bandwidth	Most other Wi-Fi devices, such as the CR310-WIFI, CR300-WIFI, CR350-WIFI, NL241
CR6-RF407	902 to 928 MHz Frequency Hopping Spread Spectrum	RF407, CR300-RF407, CRVW3-RF407, CR350-RF407
CR6-RF412	915 to 928 MHz Frequency Hopping Spread Spectrum	RF412, CR300-RF412, CRVW3-RF412 , CR350-RF412
CR6-RF422	868 MHz SRD860 LBT+AFA	RF422, CR300-RF422, CRVW3-RF422, CR350-RF422
CR6-RF452	902 to 928 MHz, 1 W Frequency Hopping Spread Spectrum	RF450, RF451, RF452, CR6-RF451, CR350-RF452

Enclosures

The CR6 and its power supply can be housed in any of our standard enclosures.

Power

The CR6 uses an external power source and has a built-in charger/regulator. Intelligent power sourcing autoselects the highest voltage from three input sources (CHG, BAT, or USB) to operate in one of the following four modes:

UPS (recommended)—A 16 to 32 Vdc source, solar panel (SP10, SP20), or power converter is used to charge a 12 Vdc battery, such as our BP7, BP12, or BP24.
12 Vdc battery or other reliable 12 Vdc source
Charge only—dc power supply (16 to 32 Vdc)
USB—Powered over 5 Vdc USB port for setup, programming, and testing (will not charge battery or boost USB power to provide 12 Vdc to the SW12 switched battery terminals or the 12V power output terminal)

Software

CRBasic, the CR6's full programming language, supports simple or complex programming and many on-board data reduction processes. The CR6 is compatible with CRBasic (version 3.5 or higher).
