25-Channel Solid-State Thermocouple Multiplexer

AM25T

Limited availability

25-Channel Solid-State Thermocouple Multiplexer

Pricing

Qty

Model:: AM25T
Item Number:: 42811
Warranty:: 1 year

Overview

The AM25T 25-Channel Solid State Multiplexer increases the number of thermocouples that you can measure using a Campbell Scientific data logger. The multiplexer interfaces with the data logger and adds terminals so that you can wire additional thermocouples or other low-level voltage output sensors.

Key Advantages

Connects Many Thermocouples
Several AM25Ts can connect
to one data logger

Technical Description

Up to 25 thermocouples are sequentially connected to a common differential channel on the AM25T. (Note: Other low-level voltage output sensors that do not exceed the common mode range of the data logger can also be measured. The AM25T should NOT be used to measure resistive bridges or configured with a voltage divider between the AM25T and the data logger; ask about our AM16/32B multiplexer for these applications.) The output from this channel is wired to a differential input channel on the data logger. As the AM25T sequentially changes channels, the data logger measures the output from each thermocouple in sequence.

A PRT attached to the AM25T’s grounding bar provides a temperature reference for the thermocouple measurements. The heat capacity of the grounding bar and an insulated aluminum cover reduce thermal gradients along the length of the multiplexer. Reducing the thermal gradients allow more accurate measurements.

Benefits

Greatly increases the number of thermocouples a data logger can measure
Multiplexes up to 25 thermocouples
Includes an on-board PRT that serves as a reference junction
Allows several AM25Ts to be controlled by one data logger, increasing the number of thermocouples that can be measured
Uses a metallic, internal ground plane to reduce thermal gradients, which ensures more accurate measurements
Provides a vertical package for a smaller “footprint” that makes it easier to fit in a crowded enclosure
Supports a maximum cable length of 152.4 m (500 ft) when lightning protection is used

Specifications

Expandability: Assumes sequential activation of multiplexers and that each data logger channel is uniquely dedicated.
1 AM25T per CR300 or CR310
(requires OS version 6 or later)
2 AM25Ts per CR800 or CR850
3 AM25Ts per CR6
4 AM25Ts per CR1000X, CR1000, or CR3000
Internal PRT Accuracy: ±0.2°C
(-25° to +50°C)
±0.4°C
(-40° to +85°C)
Power: 9.6 to 16 Vdc (under load), unregulated
Typical Relay Resistance: 500 Ω
Maximum Switching Current: 25 mA
(Switching currents greater than 25 mA will damage the relays and render them unusable.)
CE Compliance: Conforms to EN55022-1:1995 and EN50082-1:1992.
Operating Temperature Range: -40° to +85°C
Operating Humidity Range: 0 to 95%
(non-condensing)
Dimensions: 23.6 x 5.1 x 13.2 cm
(9.3 x 2 x 5.2 in.)
Weight: 0.9 kg
(2.0 lb)

Typical Current Drain

Quiescent: 0.5 mA
Active: 1.0 mA

Enable Levels

Inactive: < 0.9 V
Active: 3.5 to 5 V

Clock

Levels: Scan advance occurs on the falling edge of the clock pulse
(from above 3.5 V to below 1.5 V)
Minimum ON Time: 50 µs
Minimum OFF Time: 60 μs

Accessories

(2)

Common Accessories

(2)

Replacement Parts

(2)

Services

(1)

16536
AM25T Calibration with Data (-40° to +85°C)
The AM25T’s PRT is calibrated to original specifications and all channels are checked to verify correct operation. Factory calibration requires an RMA (Returned Material Authorization).
Orderable

Ships With

(2)

Similar Products

(2)

Compatibility

Sensors

The AM25T is typically used with type T, E, J, or K thermocouples; different thermocouple types are also supported (depends on data logger model and operating system). The AM25T can also measure other sensors that have a low-level voltage output. However, the AM25T should NOT be used with resistive bridges or be configured with a voltage divider between the AM25T and the data logger. The AM16/32B multiplexer is available for these applications.

Software/Programming

The AM25T is controlled by the AM25T instruction in CRBasic. When using Edlog, data logger Instruction 134 is used with recently shipped versions of the data loggers; older data loggers can measure and control the AM25T with a series of data logger instructions.

Short Cut software (available free of charge from our website) supports simple programming and generates wiring diagrams for AM25T applications; older versions of Short Cut did not support multiplexers.

Enclosure Considerations

The AM25T operates in most field conditions but requires a non-condensing environment. Outdoor applications require a weather-resistant enclosure augmented by desiccant; a Campbell Scientific enclosure is recommended.

Our ENC12/14 enclosure can house up to two AM25Ts, a CR800, CR850, CR10X, CR1000, or CR3000, and a power supply. The ENC16/18 houses several AM25Ts, a CR800, CR850, CR10X, CR1000, CR3000, or CR5000, and a power supply.
