Measurement and Control Datalogger

CR310

Orderable

Measurement and Control Datalogger

Pricing

Request a quote Have pricing access? Sign in

Configuration

No Additional Coms**CR310-NAPart Number: 31967
RF407 w/900 MHz Radio**CR310-RF407Part Number: 32411
WIFI w/Wireless Modem**CR310-WIFIPart Number: 32410
CELL205 w/4G LTE CAT1, Provisioned for AT&T North AmericaCR310-CELL205-ATPart Number: 42346
CELL210 w/4G LTE CAT1 VZ, Provisioned for Verizon USCR310-CELL210-VPart Number: 42351
CELL210 w/4G LTE CAT1 VZ, Provisioned for Verizon US Static IPCR310-CELL210-VSPart Number: 42352
CELL215 w/4G LTE CAT1, No ProvisioningCR310-CELL215-NPPart Number: 35182
CELL220 w/4G LTE CAT1 for Telstra Australia/NZ, No ProvisioningCR310-CELL220-NPPart Number: 35171
CELL205 w/4G LTE CAT1 3G ATT, No Provisioning**CR310-CELL205-NPPart Number: 33809
CELL225 w/4G LTE CAT1 for Japan, No ProvisioningCR310-CELL225-NPPart Number: 35173

Qty

Select a configuration to add to your quote

Model:: CR310
Item Number:: CR310
Warranty:: 3 years

Overview

The CR310 is a multi-purpose, compact, low-cost measurement and control data logger that includes an integrated 10/100 Ethernet port and removable terminal connectors. This entry-level data logger, with its rich instruction set, can measure most hydrological, meteorological, environmental, and industrial sensors. It concentrates and makes data available over varied networks, with delivery using your preferred protocol. The CR310 also performs automated on-site or remote decision-making for control and M2M communications. The CR310 is ideal for small applications requiring long-term, remote monitoring and control.

The CR310 has multiple radio options that are suitable for different regions:

CR310-RF407: US and Canada
CR310-RF412: Australia and New Zealand
CR310-RF422: UK and EU
CR310-RF427: Brazil

Note: Campbell Scientific does not recommend the CR310 for use as a PakBus router in networks with more than 50 devices. Large arrays or string variables may also reach memory limits. For such applications, a CR1000Xe Measurement and Control Datalogger is recommended.

Key Advantages

Compact Data Logger with Ethernet
Ideal for small applications

Technical Description

Terminal Descriptions

One switched 12 V terminal (SW12V) for powering sensors or communications devices, 1100 mA @ 20°C
Two sensor excitation or continuous 0.15 to 5 V terminals (VX1, VX2) for sensor excitation or output control
Six multipurpose analog input terminals (SE1–SE6)
- Analog functions (SE1–SE6)
  - Analog inputs: six single-ended or three differential inputs with -100 to +2500 mV and ±34 mV ranges 24 bit ADC
  - 4 to 20 mA or 0 to 20 mA inputs (SE1, SE2 only)
- Digital I/O functions (SE1–SE4) consist of 3.3 V logic levels for:
  - High frequency counter (35 kHz)
  - Pulse width modulation
  - Interrupts and timer input
  - Period average (200 kHz, amplitude dependent)
Two pulse counting terminals (P_SW, P_LL)
- P_SW
  - Switch closure (150 Hz)
  - High frequency counter (35 kHz)
- P_LL
  - Low level ac (20 kHz)
  - High frequency counter (20 kHz)
Two control terminals (C1, C2): C terminals are software configurable for digital functions.
- Digital I/O functions consist of 5 V output and 3.3 V input logic levels for:
  - SDI-12
  - High frequency counter (3 kHz)
  - Switch closure (150 Hz)
  - General status/control
  - Voltage source 5 V: 10 mA @ 3.5 V
  - Interrupts
  - Serial asynchronous communications Tx/Rx pair

Benefits

Set up easily with PC software and USB connectivity
Measure analog and digital sensors with confidence
Internet ready (email, FTP, HTTP/web, TCP) with required add-ons
Trust in the Campbell Scientific quality, including integral surge and ESD protection
Save money and space using the integrated Ethernet port
Network wirelessly to another node or Internet gateway with integrated radio option
CR310-WIFI ideal for short-range, wireless IP communications
Wiring made easy through removable terminal block
Communicate from anywhere when using cellular or satellite peripheral
Charge batteries using the integrated 12 V battery solar charge regulator
Measure smart sensors using RS-232 or SDI-12
Connect with PakBus, Modbus, DNP3, GOES, and other standard communications protocols
Analyze and control with programmability and multiple general purpose I/O
Notify with event-driven communications and physical outputs

Specifications

-NOTE-: Additional specifications are listed in the CR300-Series Specifications Sheet.
Operating Temperature Range: -40° to +70°C
(standard)
Non-condensing environment
Maximum Scan Rate: 10 Hz
Case Material: Powder-coated aluminum
Analog Inputs: 6 single-ended or 3 differential
(individually configured)
Pulse Counters: 8
(P_SW, P_LL, C1, C2, and SE1–SE4)
Voltage Excitation Terminals: 2
(VX1, VX2)
Communications Ports: USB Micro B
RS-232
10/100 Ethernet RJ45
Switched 12 Volt: 1 terminal
Digital I/O: 7 terminals (C1, C2, P_SW, and SE1–SE4) configurable for digital input and output
Includes status high/low, pulse width modulation, external interrupt, and communications functions. Exception: The SE4 terminal doesn't do external interrupt.
Input Limits: -100 to +2500 mV
Analog Voltage Accuracy: Accuracy specifications do not include sensor or measurement noise.
±(0.04% of measurement + offset) at 0° to 40°C
±(0.1% of measurement + offset) at -40° to +70°C
ADC: 24-bit
Charge Terminal Characteristics (CHG+ and CHG-): Input from power converter or solar panel
ES1 PS2 energy sources only
(Energy Source Class 1 [ES1] and Power Source Class 2 [PS2], as defined in Clauses 5 and 7 of IEC/AS/NZS 62368-1:2022)
16 to 32 Vdc
Hold current limit 1.6 A @ 20°C
Battery Terminal Characteristics (BAT+ and BAT-): Input from external battery, 7 Ah lead-acid typical
Voltage input 12 Vdc only
Hold current limit 1.6 A @ 20°C
Internal Lithium Battery: 3 V coin cell CR2032X for battery-backed clock
6-year life with no external power source
Real-Time Clock Accuracy: ±1 min. per month
Internet Protocols: Ethernet, PPP, RNDIS, ICMP/Ping, Auto-IP (APIPA), IPv4, IPv6, UDP, TCP, TLS (v1.2), DNS, DHCP, SLAAC, NTP, Telnet, HTTP(S), FTP(S), SMTP/TLS, POP3/TLS
Communications Protocols: PakBus, Modbus, DNP3, SDI-12, TCP, UDP, and others
CPU Drive/Programs: 80 MB serial flash
Data Storage: 30 MB serial flash
Idle Current Drain, Average: 10 mA
(@ 12 Vdc with Ethernet link idle)
Active Current Drain, Average: 56 mA
(@ 12 Vdc with Ethernet link active, processor always on)
Dimensions: 16.26 x 7.62 x 5.68 cm
(6.4 x 3.0 x 2.2 in.)
Weight: 288 to 306 g
(0.64 to 0.68 lb) depending on communications option selected

CR310-RF407 Option

Radio Type: Frequency Hopping Spread Spectrum
(FHSS)
Output Power: 5 to 250 mW
(user-selectable)
Frequency: 902 to 928 MHz
(US, Canada)
RF Data Rate: 200 kbps
Receive Sensitivity: -101 dBm
Antenna Connector: RPSMA (external antenna required; see www.campbellsci.com/rf407 for Campbell Scientific antennas)
Idle Current Drain, Average: 12 mA (@ 12 Vdc)
Active Current Drain, Average: < 80 mA (@ 12 Vdc)

CR310-RF412 Option

Radio Type: Frequency Hopping Spread Spectrum
(FHSS)
Output Power: 5 to 250 mW
(user-selectable)
Frequency: 915 to 928 MHz
(Australia, New Zealand)
RF Data Rate: 200 kbps
Receive Sensitivity: -101 dBm
Antenna Connector: RPSMA (external antenna required; see www.campbellsci.com/rf412 for Campbell Scientific antennas)
Idle Current Drain, Average: 12 mA (@ 12 Vdc)
Active Current Drain, Average: < 80 mA (@ 12 Vdc)

CR310-RF422 Option

Radio Type: 868 MHz SRD 860 with Listen Before Talk (LBT) and Automatic Frequency Agility (AFA)
Output Power: 2 to 25 mW
(user-selectable)
Frequency: 863 to 870 MHz
(European Union)
RF Data Rate: 10 kbps
Receive Sensitivity: -106 dBm
Antenna Connector: (External antenna required; see www.campbellsci.com/rf422 for Campbell Scientific antennas)
Idle Current Drain, Average: 9.5 mA
Active Current Drain, Average: 20 mA

CR310-RF427 Option

Radio Type: Frequency Hopping Spread Spectrum
(FHSS)
Output Power: 5 to 250 mW
(user-selectable)
Frequency: 902 to 907.5 MHz
915 to 928 MHz
(Brazil)
RF Data Rate: 200 kbps
Receive Sensitivity: -101 dBm
Antenna Connector: RPSMA
(External antenna required.)
Idle Current Drain, Average: 12 mA (@ 12 Vdc)
Active Current Drain, Average: < 80 mA (@ 12 Vdc)

CR310-WIFI Option

Operational Modes: Client or Access Point
Operating Frequency: 2.4 GHz, 20 MHz bandwidth
Antenna Connector: Reverse Polarity SMA
(RPSMA)
Antenna: pn 16005 unity gain (0 dBd), 1/2 wave whip, omnidirectional with articulating knuckle joint for vertical or horizontal orientation
Transmit Power: 7 to 18 dBm
(5 to 63 mW)

CR310-CELL205 Option

-NOTE-: The CR310-CELL205 option is not compatible with a Verizon cellular network.
Cell Technologies: 3G
(UMTS/HSPA+)
4G
(LTE CAT-1)
3G Frequency Bands: 850, 1700/2100 (AWS), and 1900
4G Frequency Bands: 700, 850, 1700/2100 (AWS-1), and 1900
Antenna Connector: SMA
(External antenna required; see www.campbellsci.com/cr310 for Campbell Scientific antennas)
SIM Interface: 3FF (6 position/contacts)

Supports SIMs that require 1.8 or 3 V

CR310-CELL210 Option

-NOTE-: The CR310-CELL210 option is only compatible with a Verizon cellular network.
Cell Technologies: 4G
(LTE CAT-1)
4G Frequency Bands: 700, 850, 1700, 1900, and 2100
Antenna Connector: SMA
(External antenna required; see www.campbellsci.com/cr310 for Campbell Scientific antennas)
SIM Interface: 3FF (6 position/contacts)

Supports SIMs that require 1.8 or 3 V

CR310-CELL215 Option

-NOTE-: The CR310-CELL215 option is intended for use in EMEA countries.
Cell Technologies: 2G
(GSM/GPRS/EDGE)
3G
(UMTS/HSPA+)
4G
(LTE CAT-1)
2G Frequency Bands: 900 and 1800 MHz
3G Frequency Bands: 850, 900, and 2100 MHz
4G Frequency Bands: 800, 850, 900, 1800, 2100, and 2600 MHz
Antenna Connector: SMA
(External antenna required; see www.campbellsci.com/cr310 for Campbell Scientific antennas)
SIM Interface: 3FF (6 position/contacts)

Supports SIMs that require 1.8 or 3 V

CR310-CELL220 Option

-NOTE-: The CR310-CELL220 option is intended for use in Australia and New Zealand.
Cell Technologies: 3G
(UMTS/HSPA+)
4G
(LTE CAT-1)
3G Frequency Bands: 850 and 2100 MHz
(EC-21AUT)
850, 900, 1900, and 2100 MHz
(EC-21AU)
4G Frequency Bands: 700, 850, 1800, 2100, and 2600 MHz
(EC-21AUT)
700, 900, 1700, 1800, 1900, 2100, and 2600 MHz
(EC-21AU)
Antenna Connector: SMA
(External antenna required; see www.campbellsci.com/cr310 for Campbell Scientific antennas)
SIM Interface: 3FF (6 position/contacts)

Supports SIMs that require 1.8 or 3 V

CR310-CELL225 Option

-NOTE-: The CR310-CELL225 option is intended for use in Japan.
Cell Technologies: 4G
(LTE CAT-1)
4G Frequency Bands: 800 (lower), 800 (upper), 850+, 900, 1800, and 2100 MHz
Antenna Connector: SMA
(External antenna required; see www.campbellsci.com/cr310 for Campbell Scientific antennas)
SIM Interface: 3FF (6 position/contacts)

Supports SIMs that require 1.8 or 3 V

Accessories

(18)

Common Accessories

(23)

Other Accessories

(5)

Replacement Parts

(10)

Services

(1)

31971
CR310 Calibration with Documentation
The 31971 requires an RMA (Return Material Authorization) from Campbell Scientific. When ordered, we recalibrate the CR310 to meet original specifications. Recalibration includes standard temperature testing (-40° to +70°C). Before and after calibration sheets are supplied with the CR310.
Orderable

Need Something Not Listed?

(CR310)

Don't see what you need from among these options? Download the complete configuration list below.

View all product configurations

Ships With

(7)

Similar Products

(3)

Compatibility

Measurement & Control Peripherals

The CR310 is typically not used with measurement and control peripherals because of its limited number of control ports. It is also compatible with low on current and voltage solid-state relays.

The CR310 is not compatible with SDM or CDM devices.

Sensors

With several channel types, the CR310 is compatible with nearly every available sensor. This includes analog output voltage (0 to 2.5 V) and current (0 to 20 mA or 4 to 20 mA) sensors, thermistors, and RTDs to name a few. It is also compatible with pulse or frequency output sensors such as anemometers, rain gauges, and flow meters. CR310 dataloggers are not capable of applying reverse excitation, and they cannot be used with some conductivity or soil matric potential sensors.

SDI-12, Modbus, and other serial sensors are supported with the RS-232 port and C1 and C2 as a Tx/Rx pair. The CR310 does not directly support RS-485 sensors.

Communications

The CR310 can communicate with a PC via its USB port. Compatible telemetry devices include our RS-485 converters, digital cellular gateways, RF telemetry, and satellite transmitters. Data can be viewed on an iOS device, an Android device, or CD295 DataView II Display. To use an iOS or Android device, go to the Apple Store or Google Play and download our free LoggerLink Mobile Apps.

Data Logger Option	Communications Type	Integrated Communications Are Compatible with
CR310-WIFI	2.4 GHz, 20 MHz bandwidth	Most other Wi-FI devices, such as the CR300-WIFI, CR6-WIFI, NL240
CR310-RF407	902 to 928 MHz Frequency Hopping Spread Spectrum	RF407, CR6-RF407, CRVW3-RF407
CR310-RF412	915 to 928 MHz Frequency Hopping Spread Spectrum	RF412, CR6-RF412, CRVW3-RF412
CR310-RF422	868 MHz SRD860 LBT+AFA	RF422, CR6-RF422, CRVW3-RF422
CR310-CELL	2G Frequency Bands 850, 900, 1800, 1900 3G Frequency Bands 800, 850, 900, 1900, 2100	GSM/GPRS/EDGE (2G) UMTS/HSPA+ (3G)

Software

The CR300 series is compatible with CRBasic (version 3.6 or higher).

Power

The CR310 uses an external power source and has a built-in charger/regulator. Intelligent power sourcing autoselects the highest voltage from three input sources (Chg, Bat, or USB) to operate in one of the following four modes:

UPS (recommended) - A 16 to 32 Vdc source, solar panel (SP10, SP20), or power converter (29796) is used to charge a 12 Vdc battery, such as our BP7 or BP12.
12 Vdc battery or other reliable 12 Vdc source
Chg only - DC power supply (16 to 32 Vdc)
USB - Powered over 5 Vdc USB port for setup, programming, and testing (will not charge battery or boost USB power to provide 12 Vdc to the switched battery terminal SW12)
