CR1000Xe

3768

2-Pin Screw Terminal Plug Connector

The 3768 is shipped attached to the CR1000Xe. This green, plug-in power connector provides screw terminals for connecting the 12 V and GND wires of the data logger's power supply. The 3768 may be purchased to replace a lost or damaged power connector.

42899

Battery and Desiccant Kit for the CR1000X-Series and CR6 Dataloggers

The 42899 kit provides a replacement battery and desiccant for the CR1000X-series and CR6 dataloggers. The kit consists of a single 0.16-unit silica desiccant bag and a 3.6 V 2.4 Ah lithium AA battery. When shipped, the data logger has one bag of this desiccant inside it. While the supplied desiccant should fill the initial needs of most applications, it should be periodically replaced. Campbell Scientific recommends replacing this desiccant when the data logger's internal lithium battery is replaced.

505

Screw #6-32 x .375 Pan Phillips

These screws, along with the 6044 grommets, are commonly used together to secure our equipment to the backplates of our enclosures.

6044

Grommet for #6 or #8 Screw

These grommets are commonly used with the 505 screws to secure our equipment to the backplates of our enclosures.

8125

Flat-Bladed Screwdriver, 2.5 mm Blade x 50 mm Shaft

The 8125 is a small, flat-bladed screwdriver that is extremely useful for using terminal input modules (or other peripherals with smaller terminals) with a CR1000X.

3315

Type T Thermocouple

This type T, 5 in. thermocouple is attached to a differential channel on several of our data logger wiring panels when the data logger is shipped. A 3315 may be ordered to replace a thermocouple that has become lost or damaged.

38790

USB Cable, Type A Pin (Male) to Type C Pin (Male), 6 ft

The 38790 is a USB cable for attaching a data logger to a USB port on a PC. It has a type A pin (male) connector for connecting to the PC's USB port and a type C connector for connecting to the data logger.

10645

Screw #10-32 x .312 Pan Slot, Brass

The 10645 is the screw used in the ground lug.

30028

Replacement Lithium Battery

The 30028 is a 3.6 Vdc, 2.4 Ah, AA size cell that fits inside the data logger. This lithium battery powers the clock and SRAM when external battery power, a charging source, or a USB power source is not connected.

31676

CR1000X Replacement Connectors Analog Input 1 to 4

The 31676 18-port terminal connector is shipped attached to the CR1000Xe datalogger. This lockable connector provides screw terminals for connecting sensor wires to channels of the CR1000Xe that include Analog Differential Ports 1 to 4. The 31676 may be purchased to replace a lost or damaged terminal connector.

31677

CR1000X Replacement Connectors Analog Input 5 to 8

The 31677 15-port terminal connector is shipped attached to the CR1000Xe datalogger. This lockable connector provides screw terminals for connecting sensor wires to channels of the CR1000Xe that include Analog Differential Ports 5 to 8. The 31677 may be purchased to replace a lost or damaged terminal connector.

31678

CR1000X Replacement Connectors Power Out and Communications

The 31678 18-port terminal connector is shipped attached to the CR1000Xe datalogger. This lockable connector provides screw terminals for connecting sensor wires to channels of the CR1000Xe that include C Ports 1 to 8. The 31678 may be purchased to replace a lost or damaged terminal connector.

33266

CR1000X Calibration with Data (-40 to +70C)

The 33266 provides calibration of the CR1000Xe to meet original specifications. This process includes calibration at the CR1000Xe standard temperature range (-40° to +70°C). Before and after calibration sheets are included with the calibration. An RMA (Return Material Authorization) from Campbell Scientific is required.

33267

CR1000X Extended Temperature Test (-55 to +85C)

The 33267 testing must be purchased in conjunction with the 33266 Calibration. The 33266 provides calibration of the CR1000Xe to meet original specifications. The 33267 process includes testing at the CR1000Xe extended temperature range (-55° to +85°C). Testing at the extended temperature range is only available for a CR1000Xe that previously passed the extended temperature testing. An RMA (Return Material Authorization) from Campbell Scientific is required.

34156

CR1000X Calibration over Temperature and ISO/IEC 17025 Calibration Verification with Certificate

The 34156 provides factory calibration of the CR1000Xe to meet original specifications, then sends the calibrated data logger to be verified by a certifying body that is accredited to the ISO 17025 standards.

This service requires an RMA (Return Material Authorization) from Campbell Scientific. The factory calibration includes comprehensive testing of all data logger functions over its standard temperature range (-40° to +70°C) and the replacement of the internal lithium battery and desiccant packs. During testing, the data logger’s operating system is updated, and all settings are restored to factory defaults unless otherwise requested. Upon completion of the factory calibration, the data logger is sent to the ISO 17025 accredited certifying body referenced above for calibration verification.
